PN16 Brass slide fitting, made of brass body and brass sleeve, includes different kinds of Straights, Elbows and Tees, can connect both Pex-a pipe and Pex-b pipe with size 16mm*2.2mm, 20mm*2.8mm, 25mm*3.5mm and 32mm*4.4mm for water and heating system. Brass slide fitting, the Female Elbow, DZR brass, meets Australian WaterMark Standard, with extremely long usage life. Product sizes: 16mmx1/2”, 20mmx1/2”, 20mmx3/4”, 25mmx3/4”, 25mmx1” and 32mmx1”.
Plastic copper-clad tube dimensions and allowable error table: nominal diameter copper tube outer diameter copper tube wall thickness plastic copper-clad tube outer diameter outer diameter allowable error plastic coating wall thickness plastic coating allowable error number 1.6MPa foamed flat ring Type toothed ring foam type flat ring type toothed ring 68 ± 0.090.5 ± 0.051110.210.6 ± 0.201.51.11.3 ± 0.158 ~ 10810 ± 0.090.5 ± 0.051312.212.6 ± 0.201.51.11.3 ± 0.1510 ~ 121012 ± 0.090.5 ± 0.051514.214.6 ± 0.201.51.11.3 ± 0.1512 ~ 201515 ± 0.090.9 ± 0.0918.617.618.6 ± 0.201.81.31.8 ± 0.1516 ~ 2616 ± 0.101.0 ± 0.0919.618.619.6 ± 0.201 .81.31.8 ± 0.1516 ~ 262022 ± 0.101.2 ± 0.0927.224.625.6 ± 0.202.61.31.8 ± 0.1520 ~ 302528 ± 0.151.5 ± 0.1033.230.631.6 ± 0.202.61.31.8 ± 0.1520 ~ 303235 ± 0.151 .5 ± 0.1040.638.640 ± 0.252.81.82.5 ± 0.2028 ~ 354042 ± 0.152.0 ± 0.104845.647 ± 0.253.01.82.5 ± 0.2032 ~ 4244 ± 0.152.0 ± 0.105047.649 ± 0.253.01.82.5 ± 0.2032 ~ 425054 ± 0.222.0 ± 0.15615860 ± 0.353.52.03.0 ± 0.2542 ~ 5255 ± 0.222.0 ± 0.15625961 ± 0.353.52.03.0 ± 0.2542 ~ 52
